Sulcus-Fixated IOL: Lens Choice and Power Adjustment

A sulcus-fixated IOL is a lens that surgeons place in front of the capsular bag, in the ciliary sulcus. They use it when the posterior capsule is lost but the anterior capsule is still intact.

It is the commonest backup after posterior capsule rupture.

It works well when surgeons use the right lens in the right way.

Mistakes in lens design or power can cause lasting problems.

When a Sulcus-Fixated IOL Is Possible

A sulcus lens needs sufficient support from the anterior capsule remnant and the ciliary sulcus.

Posterior capsule rupture with an intact anterior capsulorhexis, the classic indication (see vitreous loss in cataract surgery)
Zonular loss that is limited, with enough remaining support
Late dislocation in the bag, with a stable anterior capsule
Secondary lens placement in an aphakic eye with a residual capsule rim

If the anterior capsule is also lost, or the zonules are very weak, you need an alternative method of fixation, such as an iris-fixated or scleral-fixated lens (see iris-claw IOL).

Choosing the Lens

The right lens is a three-piece design with a large overall diameter, commonly 13 millimeters or more, with rounded, thick haptics.

Three-piece lenses have a stiffer haptic that holds well in the sulcus and a smooth edge.

Manufacturers do not design single-piece acrylic lenses for the sulcus, because their haptics are thick and sharp and can chafe the iris and ciliary body.

A report from the American Society of Cataract and Refractive Surgery committee reviewed complications of placing single-piece acrylic lenses in the sulcus, including pigment dispersion, glaucoma, hyphema, and lens decentration, and recommended the use of a three-piece lens as a backup.

Test your knowledge 10 questions from this article

Adjusting the Lens Power

A lens in the sulcus sits about 0.5 to 1.0 millimeter in front of its position in the bag, so its effective power is higher.

Also, the surgeon reduces the power to prevent a myopic surprise, commonly by about 0.5 diopter for lenses of moderate power. The reduction is larger for higher-power lenses, according to a chart or the lens manufacturer’s advice.

Some modern calculators have a setting for sulcus placement, and the surgeon should use it.

Optic Capture

In an eye with an intact capsulorhexis that is smaller than the optic, the surgeon can place the haptics in the sulcus and push the optic posteriorly through the rhexis.

This holds the lens in the center, stabilizes it against the capsule, and reduces the risk of pigment dispersion and decentration.

It also moves the optic back toward the plane of the bag, so the power adjustment is smaller.

The method needs a rhexis of the right size and a complete anterior capsule edge.

Sulcus-Fixated IOL: Lens Choice and Power Adjustment

Complications of Sulcus-Fixated IOL

Uveitis-glaucoma-hyphema syndrome, from the chafing of the lens against the iris and ciliary body (see uveitis-glaucoma-hyphema syndrome)
Pigment dispersion and raised pressure
Decentration, tilt, and pupillary capture
Cystoid macular edema (see Irvine-Gass syndrome)
Postoperative astigmatism and refractive surprise if the surgeon does not adjust the power

Patients should have follow-up that includes the pressure and the lens position, particularly if there is any pain or reduced vision.

Sulcus-Fixated IOL: Technique Tips

Fill the sulcus with viscoelastic, inspect the capsule rim, and measure the sulcus-to-sulcus distance if possible.

Place the lens gently, with the haptics oriented at the intact capsule support and away from any zonular gaps.

Consider constricting the pupil with an agent, and remove the viscoelastic carefully.

Document the lens model, the position, and the power adjustment, so that later teams know what the surgeon did.

Alternatives When the Capsule Is Insufficient

If the anterior capsule is inadequate, consider scleral fixation, iris fixation, or an anterior chamber lens, depending on the eye (see iris-claw IOL and scleral-fixated intraocular lens).

If the surgeon is not equipped for these procedures, the safest course may be to leave the eye aphakic and plan a secondary lens at a later date. Do not force an unsafe lens into the sulcus.

Avoid placing a lens on a bed of vitreous, and complete the vitrectomy before implanting.

After Surgery

Review the pressure, the lens position, and the anterior chamber reaction at the first visits.

Use topical steroids and nonsteroidal drops according to the case, and consider extended monitoring for macular edema.

If pigment dispersion, raised pressure, or hyphema occurs, consider exchanging the lens or repositioning it, since chronic irritation worsens over time.

Tell patients that a lens in the sulcus should stay stable for life, and that any sudden change in vision, pain, or redness needs urgent examination.

References

Chang DF, Masket S, Miller KM, et al. Complications of sulcus placement of single-piece acrylic intraocular lenses: recommendations for backup IOL implantation following posterior capsule rupture. J Cataract Refract Surg. 2009;35:1445-1458.
Wagoner MD, Cox TA, Ariyasu RG, Jacobs DS, Karp CL. Intraocular lens implantation in the absence of capsular support: a report by the American Academy of Ophthalmology. Ophthalmology. 2003;110:840-859.
Salmon JF. Kanski’s Clinical Ophthalmology: A Systematic Approach. 9th ed. Elsevier; 2020.
American Academy of Ophthalmology. Basic and Clinical Science Course, Section 11: Lens and Cataract. AAO; current edition.
