Diabetic Retinopathy Classification: ICDR and ETDRS Scales

Diabetic retinopathy classification gives clinicians a common language for the stage of disease. It also links each stage to a referral interval and a treatment decision.

Two systems dominate practice. The ETDRS scale was built for research, while the International Clinical scale was designed for the clinic.

Therefore, knowing both helps you read reports, talk with colleagues, and apply the guidelines.

Diabetic Retinopathy Classification: The Two Systems

The Early Treatment Diabetic Retinopathy Study graded fundus photographs in seven fields. Its severity scale has many steps, and each step predicts the risk of progression.

The scale remains the research standard. However, a scale with that many levels is not practical at the bedside.

In 2003, an international consensus group proposed a simpler clinical scale. It has five levels of retinopathy and a separate scale for macular edema.

The group built the scale from ETDRS data. As a result, clinicians can teach it and apply it without photographs.

The International Clinical Scale

No apparent retinopathy: the retina shows no abnormalities
Mild nonproliferative: the retina shows microaneurysms only
Moderate nonproliferative: the retina shows more than microaneurysms but less than severe disease, such as dot and blot hemorrhages, hard exudates, and cotton wool spots
Severe nonproliferative: the retina meets any one of the 4-2-1 criteria
Proliferative: the eye shows neovascularization, vitreous hemorrhage, or preretinal hemorrhage

Clinicians grade macular edema as absent, mild, moderate, or severe. The grade depends on the distance of the exudates or thickening from the center of the macula.

The scale applies to retinopathy seen on clinical examination. Therefore, OCT findings alone do not change the grade.

Test your knowledge 10 questions from this article

The 4-2-1 Rule in Diabetic Retinopathy Classification

Severe nonproliferative retinopathy is present when any one of the following appears.

4: severe intraretinal hemorrhages and microaneurysms in all four quadrants
2: venous beading in two or more quadrants (see venous beading)
1: intraretinal microvascular abnormalities in one or more quadrants (see intraretinal microvascular abnormalities)

The rule comes from an ETDRS finding. These features carried a high risk of progression to proliferative disease within one year.

Because of that risk, clinicians often treat these eyes or follow them closely, depending on the other risk factors.

Why Diabetic Retinopathy Classification Changes Management

First, each stage carries a different risk of progression and a different follow-up interval.

Eyes with no or mild disease can return at yearly intervals. Moderate disease usually needs shorter intervals, depending on the guideline in use.

Severe and proliferative disease call for referral to a retina specialist. That specialist then decides between laser and anti-VEGF therapy (see proliferative diabetic retinopathy and panretinal photocoagulation).

Macular edema that involves the center needs treatment whatever the retinopathy level (see diabetic macular edema).

Diabetic Retinopathy Classification: ICDR and ETDRS Scales

Practical Notes

Dilate the pupil and examine all four quadrants, since peripheral lesions can raise the grade
Use photographs, and widefield imaging when available, because documented findings are easier to compare over time (see ultra-widefield retinal imaging)
Always record both the retinopathy grade and the macular edema grade in the chart
Remember that screening programs in many countries use their own simplified grades, such as R and M levels, which map onto the clinical scale
Re-grade after a significant change in glycemic control, pregnancy, or cataract surgery

Moreover, telling the patient the stage of disease improves adherence to follow-up. It also helps control of blood glucose, blood pressure, and lipids.

Screening Programs and Referral

National screening programs use grades that correspond to the clinical scale. These grades decide who needs a specialist and how soon.

In general, clinicians refer eyes with proliferative disease, severe nonproliferative disease, or central macular edema urgently, within a few weeks.

Eyes with moderate disease may return at shorter intervals, while eyes with mild or no disease return at routine intervals.

The ophthalmologist who receives a referral should review the images and regrade them, because screening images can underestimate peripheral disease.

Limitations

The clinical scale grades only what the fundus shows. It leaves out OCT thickness, nonperfusion on angiography, and peripheral lesions visible only on widefield images.

Recent widefield studies suggest that mainly peripheral lesions may carry extra risk, so the scale may evolve.

For now, use the classification as a guide, and combine it with the whole clinical picture. Include systemic risk factors, pregnancy, and the speed of change.

When you write the report, state the grade for each eye separately, because the two eyes can differ. Also state whether macular edema is present and where.

Overall, a clear, consistent grade in the chart makes the next visit more useful to every clinician who sees the patient.

References

Wilkinson CP, Ferris FL III, Klein RE, et al. Proposed international clinical diabetic retinopathy and diabetic macular edema disease severity scales. Ophthalmology. 2003;110:1677-1682.
Early Treatment Diabetic Retinopathy Study Research Group. Grading diabetic retinopathy from stereoscopic color fundus photographs: an extension of the modified Airlie House classification. ETDRS report number 10. Ophthalmology. 1991;98:786-806.
Ryan SJ, Schachat AP, Wilkinson CP, et al, eds. Retina. 6th ed. Elsevier; 2018.
American Academy of Ophthalmology. Basic and Clinical Science Course, Section 12: Retina and Vitreous. AAO; current edition.
